Home / Solutions / Residents
Built for :
Residents
In regions like Africa, access to clean drinking water is a
significant challenge. Samking solar water pumps provide advanced, affordable solutions to these areas. our
pay-as-you-go system enables distributors to reach
more people, making clean water accessible.
01/05
What’s the Secret
Behind it:
•
The system reduces electricity costs and offers an eco-friendly solution for pool maintenance.
•
A solar-powered pool pump uses energy from solar panels to power the pump, circulating water through the filter without relying on the electric grid.
•
Offering a hybrid AC/DC power source, ensuring reliable water circulation in all weather conditions, with solar panels installable on the roof or in a sunny yard spot.
02/05
Whether installing a new system or upgrading an existing one, we'll guide you through the essential information you need to get started.
Create Your Own
Watering System:
01- Learn How to Pick the
Ideal Solar Pump
Considering your water source, lift, distance, daily needs, Ensure the pump's head and flow rate match your requirements, pair it with appropriately sized panels.
• What is the water source? (Borehole or River)
• Lift from the water surface to the ground? (H1)
• Horizontal distance of water transport? (L)
• The daily water requirement? (m³/day)
• Height of the tank? (H2)
ACTUAL LIFT HEAD
= H1 + H2 + 10%L
KEY CRITERIA (1)
Model Max H * 70% > H1 + H2 + 10%L >
Max Head * 30%
KEY CRITERIA (2)
Model Max F >
Daily Water Requirement (m³/Day)
02- Calculate Lift & Head
03- Select the
Right Solar Panels
The solar panel array should be 1.3 times the water pump's power, with voltage matching the pump's range. (For the 0.3-3HP SAMKING Solar Pump Family, we recommend connecting panels in series.)
E.g.,5 Panels Connected in Series:
(410W, Vmp: 38.5V, Voc: 42.6V)
F Power = 5 x 410W = 2200W
F Vmp = 5 x 38.5V = 192.5V
F Voc = 5 x 42.6V = 213V
Ensure*
F Power ≥ Pump Power x 1.3
F Voc < Pump's Max Voc
DC Working Voltage Range (Economic Models)
Rated Power
300W/0.3HP
600W/0.5HP
1000W/0.75HP
1200W/1HP
1800W/1.5HP
2200W/2HP
3000W/3HP
Rated Voltage
20-40Vmp / Voc ≤ 48V
40-76Vmp / Voc ≤ 96V
65-110Vmp / Voc ≤ 150V
80-150Vmp / Voc ≤ 180V
110-250Vmp / Voc ≤ 440V
150-300Vmp / Voc ≤ 440V
250-380Vmp / Voc ≤ 440V
03/05
See Our
Proven Cases
Katsina, Nigeria
Samking in rural communities has loads of impressive projects, The hybrid power pump 4SP5-10 2HP delivers water from a 60-meter dynamic head, producing 6,000 litres per hour. Residents are thrilled to have plenty of water daily for drinking, cooking, and even showering.
Previously, the community relied on costly water trucks to transport water from a source located 5 km away. This inefficient and expensive method often led to frequent challenges, including delays, inconsistent supply, and high operational costs. Took a toll on the community's daily life.
04/05
Chosen Models for
Residents
3SPN2-16
Max H:
Max F:
Max Voc:
Rated Power:
120 M
5.0 m³/h
200 V
1,500 W
4SPN5-15
Max H:
Max F:
Max Voc:
Rated Power:
170 M
9.7 m³/h
450 V
3,000 W
4SPN3-18
Max H:
Max F:
Max Voc:
Rated Power:
191 M
7.0 m³/h
450 V
3,000 W
4SPN8-8
Max H:
Max F:
Max Voc:
Rated Power:
88 M
15.7 m³/h
450 V
3,000 W
05/05
We Offer
Reliable Support
Pre-Sales Support
· 24/7 availability, 1-hour responding.
· Comprehensive solutions for your needs.
· Support for Distribution, OEM, and ODM.
Contract Fulfilment
· Standardised service & inspection.
· Rigorous product checks.
· Order and logistics tracking.
Post-Sales Service
· 2 year warranty with 24-hour support.
· Installation, and maintenance assistance.
· Online training available.
